Working Pressure: 22Mpa
Rated power: 14.2kW
Maximum excavation force: 22KN
MKD-25 Mini excavator
Overview
The MKD-25 mini crawler excavator is a high-performance compact construction machine designed for confined-space operations. It is equipped with the globally recognized Kubota D1105 diesel engine and a full set of Hengli brand hydraulic systems, balancing stable power output with smooth and precise handling. Its undercarriage supports width adjustment from 1100mm to 1440mm, allowing flexible passage through restricted spaces like doorways and alleys, while ensuring stability for heavy-load operations in extended mode.
Specifications
| Model | MKD-25 |
Engine | Kubota D1105/14.2kW |
Working Pressure | 22Mpa |
Maximum excavation force | 22KN |
Maximum excavation depth | 2650mm |
Maximum excavation distance | 4450mm |
Maximum vertical arm digging depth | 2300mm |
Maximum excavation height | 4000mm |
Maximum unloading height | 2800mm |
Minimum turning radius | 1720mm |
Track width | 1100-1440mm |
Bulldozer blade height and width | 280*1440mm |
Hydraulic flow rate | 60L/min |
Ground pressure | 24Kpa |
1. Kubota Original Engine with Fuel Efficiency & Global Support
Powered by the Kubota D1105 diesel engine with a rated power of 14.2kW, it delivers smooth and strong power output with excellent fuel economy and low operating noise. Kubota boasts a comprehensive global after-sales service and spare parts supply network, ensuring low failure rate, convenient maintenance, and controllable long-term operating costs. It is the most recognized power solution for mini excavators in overseas markets.2. Retractable Crawler Undercarriage for All-Scene Access
The overall chassis width is freely retractable between 1100mm and 1440mm. In retracted mode, the ultra-narrow body easily passes through restricted spaces such as standard doorways, yard gates and country alleys. In extended mode, the larger ground contact area significantly improves overall stability for safer heavy-load digging. One machine satisfies both narrow-space access and full-site operation needs.3. Full Hengli Hydraulic System for Precise & Responsive Control
The multi-way valve, hydraulic pump, swing motor and travel motor all adopt Hengli brand hydraulic components. The system operates at a working pressure of 22MPa with a hydraulic flow rate of 60L/min. The well-matched hydraulic system delivers smooth compound movements, delicate and precise handling, and seamless transitions between digging, swinging and traveling for high working efficiency. The excellent sealing performance reduces oil leakage risks during long-term use.
4. Ultra-Tight Turning Radius for Confined-Space Flexibility
It is fitted with a 1440mm wide and 280mm high dozer blade, which can independently complete site grading, soil backfilling and working area cleaning. It can also support the machine body during digging to further improve operation stability. No additional bulldozer is needed, and one machine can complete a full set of small earthwork processes, effectively reducing supporting equipment investment.
5. Multi-Attachment Expandability for Full-Scenario Adaptation
Standardized hydraulic interfaces and a mature hydraulic system support quick replacement of various attachments such as breakers, augers, wood grabs and rakes. It can switch between different operation modes such as breaking, drilling, grabbing and cleaning, covering diverse engineering needs including landscaping, municipal maintenance, agricultural planting and house demolition, greatly improving equipment utilization and return on investment.For inquiries regarding the price, specifications, or configuration details of the MKD-25 Mini excavator , please contact us.
