Self weight: 2.7 T
Dimensions: 3.5*0.8*1.85m
Max operating radius: 10 m
MKDZ-3T Spider Crane
Overview
The MKDZ-3T Mini Crawler Spider Crane is a 3-ton high-performance compact lifting device, standardly equipped with a dual-power system of diesel engine and AC motor, balancing long-duration outdoor operation and zero-emission low-noise indoor construction. It is fitted with a 6-section high-strength telescopic boom, reaching a maximum lifting height of 10.8m and a maximum safe operating radius of 10m, with full boom extension completed in 20 seconds. With a body width of only 800mm, it smoothly passes through doorways, narrow alleys and confined spaces. Paired with a wide-temperature starting system, low-noise operation design and wide crawler chassis, it adapts to extreme climates and complex terrains. It supports multiple options including load moment controller, wireless remote control and working basket, and is widely applied to curtain wall installation, workshop equipment maintenance, municipal landscape construction, overhead pipeline installation and other lifting scenarios.
Specifications
| Model | MKDZ-3T |
Rated Lifting Capacity | 2.7 t |
Max Vertical Lifting Height | 10.8 m |
Max Safe Operating Radius | 10 m |
Telescopic Boom form | 2.4mx6-section lifting arm (Support customization) |
Boom length/time | 3.1m-10.8m/20sec(adjustable) |
Overall Transport Dimensions (L×W×H) | 3500 × 800 × 1850 mm |
Winches Hook Rising Speed | 0-8m/min (4 ropes) |
Winches Wire Rope Specifications | Ф8mm*45m |
Track | 220mm(width)72mm(pitch)50mm(section) |
1. 3 Ton Rated Lifting Capacity with 2.7 Ton Lightweight High Load-to-Weight Ratio
With a rated lifting capacity of 3 tons and a self-weight of only 2.7 tons, it delivers an outstanding load-to-weight ratio among compact spider cranes of the same class. It balances strong lifting performance and transport flexibility, meeting the hoisting demands of medium steel structures, industrial equipment and building components.
2. 10.8m Maximum Lifting Height Covering Mid-High Rise Operation Scenarios
The maximum above-ground lifting height reaches 10.8m when the boom is fully extended, covering mid-height lifting scenarios such as multi-story building facade construction, high-position equipment hoisting in workshops and overhead pipeline erection, expanding the working height boundary of mini lifting equipment.3. 6-Section High-Strength Telescopic Boom, 20s Fast Adjustable Extension
Adopting a 2.4m×6-section high-strength telescopic boom structure, the boom length is steplessly adjustable from 3.1m to 10.8m, and full-stroke extension takes only 20 seconds. It quickly adapts to working conditions of different heights and radii, greatly shortening on-site preparation time, and boom parameters are customizable.
4. Standard Dual-Power System, All-Scenario Compatibility Reduces Procurement Cost
Unlike most single-power spider cranes in the same class, the MKDZ-3T comes standard with a diesel-electric dual-power system directly from the factory, no extra paid upgrade needed. Diesel power ensures endurance for long-distance outdoor operation, while electric mode enables zero-emission low-noise construction in enclosed indoor spaces. One machine covers all indoor and outdoor scenarios, effectively reducing customers' investment in multiple equipment.
5. All-Weather and All-Terrain Adaptability, Strong Global Market Environmental Compatibility
Excellent noise control combined with zero-emission electric mode meets strict environmental protection and noise control standards in urban areas, residential zones and historical building protection areas in developed European and American countries. It greatly reduces construction compliance risks and nuisance complaints, helping customers undertake more municipal and commercial projects with high environmental requirements.For inquiries regarding the price, specifications, or configuration details of the MKDZ-3T Spider Crane , please contact us.
