Drilling depth:150m
Drilling diameter: 100-300mm
Main motor power: 22Ps
MKD-150 Water Well Drilling Rig
Overview
The MKD-150 is a 22-horsepower single-cylinder wheeled diesel water well drilling rig, capable of reaching a maximum drilling depth of 200 meters, with a torque of 1000 N·m and a lifting capacity of 5000 kilograms. This rig boasts a compact structure and is easy to carry, making it highly suitable for residential, agricultural, and small-scale engineering drilling projects.
Specifications
| Model | MKD-150 |
| Drilling Depth | MAX.180-200 |
| Drilling Hole Diameter | 60-460mm |
| Rig Power | 22HP |
| Starting Voltage | 12V |
Advance the Process all at once | 8-16m |
Engine Model | Changchai1115M |
Maximum Speed of Power Head | 148-150r/min |
Hydraulic Oil Tank Capacity | 35L |
Rotating Form of Power Head | Rotary Type |
| Maximum Torque of Power head | 1000N·m |
Work Quality | 5000KG |
Operating State Dimensions | 2800*1200*2650mm |
Key Features
1.22 horsepower single-cylinder diesel power unit
The equipment is equipped with a Changchai 1115M single-cylinder diesel engine, capable of reaching a maximum speed of 2200 rpm. It can provide stable independent power for off-grid drilling in the wilderness without requiring an external power source.
2.Wheeled compact chassis for flexible transportation
Features a wheeled trailer chassis with 19008501600mm non-operating size, towable by ordinary vehicles and suitable for drilling in narrow spaces like residential yards and farmlands.
3.Stable Full Hydraulic Drive System
Equipped with a 200m³/h gear pump and 35L hydraulic oil tank, the integrated hydraulic system ensures smooth action switching, low failure rate and simple daily maintenance.
4.Multi-Scene Adaptability for Various Formations
Widely applicable to residential drinking wells, agricultural irrigation boreholes and small dewatering projects, and works reliably on soil, clay, weathered rock and gravel layers.
5.1000N·m High-Torque Rotary Power Head
Adopts rotary power head structure with 1000N·m max torque and 148-150r/min working speed, delivering steady penetration performance for both soil and weathered rock formations.
For inquiries regarding the price, specifications, or configuration details of the MKD-150 hydraulic water well drill, please contact us.
